HX-ZJJ-C
Pper core machine
Equipment Introduction
The paper core produced by this machine is widely applicable to the paper making,plastic,medical and packing industry.This machine can cut tubes automatically with even cut and precise length as requested.
Technical Parameter
| Main engine | it is electromagnetic speed governing engine, and its power is 5.5Kw |
| Engine of paper core cutting | it is cycloidal engine,and its power is 0.75kw |
| Diameter of producing paper core (tube)( mm) | 10-80 |
| Thickness of producing paper core (tube)( mm) | 1-5 |
| Production speed( m/minute) | 10 -16 |
| Configuration of glue stand: | 12 layers |
| Configuration of craft paper jumbo rolls | 15 layers |
| Tube Winding device | 1 set |
